NSK Bearing NJ336 EM Cylindrical Roller Bearing size chart
- Samples:
- 180mm , 380mm
$148.66/Piece | 1 Piece (Min. Order) |
- Lead Time If you finish the payment today, your order will ship out within the delivery date.
:
Quantity(Pieces) 1 – 2000 >2000 Est. Time(days) 3 To be negotiated
- Customization:
- Customized logo(Min. Order: 1000 Pieces)Customized packaging(Min. Order: 1000 Pieces)
More
NSK Bearing NJ336 EM Cylindrical Roller Bearing size chart
Cylindrical rollers and raceways are linear contact bearings. Load capacity mainly bears the radial load. The friction between the rolling element and the retaining edge of the ring is small, which is suitable for high-speed rotation. According to whether the ring has ribs, it can be divided into single row cylindrical roller bearings such as NU, NJ, NUP, N, NF, and double row cylindrical roller bearings such as NNU and NN. The bearing has a separable structure with an inner ring and an outer ring.
Cylindrical roller bearings with no ribs on the inner or outer ring, the inner ring and outer ring can move relative to the axial direction, so it can be used as a free end bearing. Cylindrical roller bearings with double ribs on one side of the inner ring and outer ring and a single rib on the other side of the ring can bear a certain degree of axial load in one direction. Generally use steel stamping cage or copper alloy car solid cage. But there is also a part of the use of polyamide forming cage.
Cylindrical roller bearings with no ribs on the inner or outer ring, the inner ring and outer ring can move relative to the axial direction, so it can be used as a free end bearing. Cylindrical roller bearings with double ribs on one side of the inner ring and outer ring and a single rib on the other side of the ring can bear a certain degree of axial load in one direction. Generally use steel stamping cage or copper alloy car solid cage. But there is also a part of the use of polyamide forming cage.
NJ336 EM NSK Cylindrical Roller Bearing with the size chart | ||
d | 180 mm | |
D | 380 mm | |
B | 75 mm | |
Weight | 44 Kg | |
Basic dynamic load rating (C) | 985 kN | |
Basic static load rating (C0) | 1230 kN | |
Shandong Tefule Bearing Co.,Ltd is a professional bearing manufacturer and dealer in china. We have been engaged in the bearing industry for 10 years and made international trade of bearing import and export for more than 8 years. We have our own brand “TFL” and applied ISO9001:2000 certificate for certification authority. We attend international bearing fairs, put in many B2B websites and achieve many customers all over the world also build up good reputation from our customers.
Our company is specialized in ball bearing,roller bearing,housing units, wheel hub bearing,bearing parts and accessories, cross roller bearing. Also we can customize various large non-standard products such as the most competitive products according to customers’ demands.
Our company is specialized in ball bearing,roller bearing,housing units, wheel hub bearing,bearing parts and accessories, cross roller bearing. Also we can customize various large non-standard products such as the most competitive products according to customers’ demands.
