High speed 30308 Taper Roller Bearing 7308E

Benefits:
 Quick refunds on orders under US $1,000Claim now

40mm

90mm
Samples:
40mm, 90mm

$31.30/Piece | 1 Piece (Min. Order) |

loading…
Lead Time
If you finish the payment today, your order will ship out within the delivery date.

:

Quantity(Pieces) 1 – 1000 >1000
Est. Time(days) 3 To be negotiated
Customization:
Customized logo(Min. Order: 1 Piece)
Customized packaging(Min. Order: 1 Piece)

More

  • Product Description
  • Product Specification
  • Original size:40*90*23mm 30308 Taper Roller Bearing 7308E


    303series: 30302,30303,30304,30305,30306,30307,30308,30309,30310

    Tapered roller bearings are made up of four interdependent components: The inner ring, or cone; the tapered

    rollers, or rolling elements; the roller retainer, or cage(collectively known as the cone assembly); and an outer
    race, or cup. They are designed and manufactured to ensure that their conical rollers and raceways are arranged
    so that their contact surfaces converge at a common apex on the bearing’s axis. The larger this contact angle the
    greater the bearing’s loading capacity.
    The angular construction of single row tapered roller bearings provides a high capacity for radial, axial, and
    combined loads. Tapered roller bearings have window-type pressed steel cages with no marking. Other types
    could be specifically designed on request.

    Item
    Value
    Model number
    30308/7308E
    Seals type
    OPEN
    Number of Rows
    Single row
    High speed 30308 Taper Roller Bearing 7308E
    Item
    Value
    Model number
    30308/7308E
    Seals type
    OPEN
    Number of Row
    Single row
