708C S708 H708C/P5 DTA Miniature Angular Contact Bearings

Bore Size:
8mm
Outside Diameter:
22mm
Model Number:
708C
Samples:
8mm , 22mm , 708C

$4.20/Piece | 1 Piece (Min. Order) |

loading…
Lead Time
If you finish the payment today, your order will ship out within the delivery date.

:

Quantity(Pieces) 1 – 1000 >1000
Est. Time(days) 3 To be negotiated
Customization:
Customized logo(Min. Order: 1000 Pieces)
Customized packaging(Min. Order: 1000 Pieces)

More

  • Product Description
  • 708C S708 H708C/P5 DTA Miniature Angular Contact Bearings

    Single row angular contact ball bearings can only bear axial load in one direction. When bearing radial load, the additional axial force will be caused. And it can only limit the axial displacement of the shaft or housing in one direction. Angular contact ball bearings have a contact angle of 40 degrees to withstand large axial loads. Angular contact ball bearings are of a non-separable design, and the shoulders on both sides of the inner and outer rings are different in height. To improve the load capacity of the bearing, the shoulder on one side will be processed lower so that the bearing can be loaded with more steel balls.
    Data and Pictures
    Bearing No.
    d
    D
    B
    mm
    mm
    mm
    725C
    5
    16
    5
    725A
    5
    16
    5
    706C
    6
    17
    6
    706A
    6
    17
    6
    726C
    6
    19
    6
    726A
    6
    19
    6
    707C
    7
    19
    6
    707A
    7
    19
    6
    708C
    8
    22
    7
    708A
    8
    22
    7
    728C
    8
    24
    8
    728A
    8
    24
    8
    7900C
    10
    22
    6
    7900A5
    10
    22
    6
    7901C
    12
    24
    6
    7901A5
    12
    24
    6
    7902C
    15
    28
    7
    7902A5
    15
    28
    7
    7903C
    17
    30
    7
    7903A5
    17
    30
    7
    7904C
    20
    37
    9
    7904A5
    20
    37
    9
    7905C
    25
    42
    9
    7905A5
    25
    42
    9
    7906C
    30
    47
    9
    7906A5
    30
    47
    9
    7907C
    35
    55
    10
    7907A5
    35
    55
    10
    7908C
    40
    62
    12
    7908A5
    40
    62
    12
    7909C
    45
    68
    12
    7909A5
    45
    68
    12
    7910C
    50
    72
    12
    7910A5
    50
    72
    12
    7911C
    55
    80
    13
    7911A5
    55
    80
    13
    708C S708 H708C/P5 DTA Miniature Angular Contact Bearings
    708C S708 H708C/P5 DTA Miniature Angular Contact Bearings
